Description
\
Dual 4th Gen Intel Xeon Scalable processor, dual 10GBase-T LAN ports, redundant power supply, 12 x 3.5″ SATA/SAS hot-swappable bays
Dual 4th Gen Intel® Xeon® Scalable processors, Dual Socket LGA-4677 (Socket E) , CPU TDP supports up to 350W TDP
Support CXL
Intel® C741 Chipset
920W Redundant Platinum Super Quiet power supply W/PMbus
Up to 4TB 3DS ECC RDIMM, DDR5-4800MT/s(1DPC) in 16 DIMM slots
12 x 3.5″ hot-swap SAS/SATA drive bay with SES3, optional 2 x 2.5″ hot-swap drive bay
Broadcom BCM57416 Dual ports 10G LAN
2x SATA DOM ports
2x M.2 PCIe 5.0 x4
5x PCIe 5.0 x16
1x PCIe 5.0 x8
8 SATA 3.0 ports(C741, RAID 0, 1, 5, 10)
HD Audio 7.1 channel
1 USB 3.1 Gen 2, 6 USB 3.0
Supports up to 12x SATA3 and SAS Hard Drives
Configurable with 2x Intel Intel Xeon Scalable Processors 4th Generation
Supports up to 16 modules of DDR5 ECC Registered Memory
6x PCI Express Expansion Slots
Configurable with up to 2TB Server Memory
